Model |
GSD45 |
GSD52 |
GSD56 |
GSD65 |
GSD73 |
GSD85 |
|
Ring Diameter×Height（mm） |
φ1100×200 |
φ1300×240 |
φ1400×280 |
φ1620×300 |
φ1850×300 |
φ2150×300 |
|
Roller Diameter×Height（mm） |
φ320×200 |
φ370×240 |
φ410×280 |
φ450×300 |
φ510×300 |
φ600×300 |
|
Roller Quantity（pcs） |
3/4 |
4 |
4 |
5 |
5 |
6 |
|
Main Shaft Speed（r/min） |
145 |
125 |
105-115 |
102-110 |
92 |
85 |
|
Air Volume |
24000 |
20000 |
32876 |
41500 |
75000 |
89600 |
|
Air pressure(Pa) |
4200 |
5500 |
9435 |
7400 |
3550 |
4677 |
|
Feeding Size（mm） |
≤25 |
≤30 |
≤30 |
≤30 |
≤30 |
≤40 |
| Output Size（mm） |
0.038-0.18 |
0.038-0.18 |
0.038-0.18 |
0.038-0.18 |
0.038-0.18 |
0.038-0.18 |
|
Capacity (t/h) |
1-7 |
2-10 |
3-15 |
3-18 |
6-32 |
8-40 |
| Model |
GSD45 |
GSD52 |
GSD56 |
GSD65 |
GSD73 |
GSD85 |
|
|
Grinding Mill |
Power（kW） |
45 |
55-75 |
110 |
132-160 |
220-250 |
315 |
|
Blower |
Power（kW） |
37-45 |
45-55 |
90 |
110-132 |
160 |
220 |
|
Classifier |
Power（kW） |
15 |
22 |
22 |
30 |
37 |
37 |
|
Jaw Crusher |
Model |
JCF150×250 |
JCF200×300 |
JCF250×400 |
JCF250×400 |
JCF250×750/1000 |
PC1010 |
|
Power（kW） |
5.5 |
7.5 |
15 |
15 |
22 |
110 |
|
|
Bucket Elevator |
Model |
GT210 |
GT210 |
GT210 |
GT250 |
GT315 |
TB315 |
|
Lifting Height（mm） |
5800 |
5800 |
7200 |
10000 |
10000 |
11500 |
|
|
Power（kW） |
3 |
3 |
5.5 |
5.5 |
7.5 |
7.5 |
|
|
Feeder |
Model |
GZ1F |
GZ2F |
GZ2F |
GZ3F |
B500X1.8-2.5 |
B650X1.8-2.5 |
|
|
Power（kW） |
0.06 |
0.15 |
0.15 |
0.2 |
3 |
3 |
|
Hopper |
（m³） |
1.5 |
2 |
2 |
2 |
3.4 |
3.4 |
|
Pulse Filter |
Model |
GDMC48 |
GDMC64 |
GDMC80 |
GDMC96 |
GDMC120 |
GDMC144 |
|
|
Power（kW） |
5.5 |
5.5 |
7.5 |
7.5 |
15 |
15 |
| Overall Dimension (mm) |
8200×6010×7200 |
8500×7500×8200 |
10100×9300×8330 |
10250 ×8090×10510 |
12000×11600×11000 |
12000×11600×11000 |
|
Note: The production is based on open-circuit condition when bulk density of feeding is 1.6t/ m3. It is also relative to physics character,type of feeding, input size and composition etc. Sandmine machinery reserves all rights to change data without notice.
